Painting flowers with code

As this blog post shows, you can train a model to create watercolour sketches of flowers using p5.brush, and use a judge to do pairwise comparisons against a reference pool of images for the reward function.

In this tutorial, we train Qwen3.5-4B and use HuggingEnvs/watercolour-reference-pool as the reference pool. During each rollout, sketches are rendered to PNGs in a Modal Sandbox and Qwen3.6-27B compares each against the reference image pool.

import asyncio
import base64
import itertools
import random
import sys
from argparse import Namespace
from collections.abc import Awaitable, Callable
from pathlib import Path
from typing import Any, Protocol

from modal_dojo import (
    DatasetConfig,
    Endpoint,
    Qwen3_5_4B,
    Qwen3_5_4B_Recipe,
    Qwen3_6_27B,
    Sandbox,
    TrainConfig,
)
from modal_dojo.common.sample_extraction import IMAGE_SAMPLE_LIMIT_ENV

sys.path.insert(0, str(Path(__file__).resolve().parent))
import helpers

base_model = Qwen3_5_4B()

Get the dataset

Using the present species and palette colors, we create a set of prompts to train our model.

SPECIES = ["hibiscus"]
PALETTES = [
    "peach",
    "crimson",
    "butter",
    "lilac",
    "coral",
    "indigo",
    "blush",
    "amber",
]

SYSTEM_PROMPT = """\
You paint watercolours by writing a p5.js 2.x sketch that uses the p5.brush library, available as the global `brush`.

Reply with one ```javascript fence containing a complete sketch, and nothing else.

Use exactly this skeleton:

  async function setup() {
    createCanvas(600, 600, WEBGL);
    brush.scaleBrushes(3);
    angleMode(DEGREES);
    noLoop();
  }

  function draw() {
    translate(-width / 2, -height / 2);
    background(hex);
    // painting goes here
  }

So: angles are in degrees, and after the translate the canvas runs from 0 to 600 on both axes with the origin at the top LEFT, not the centre. The centre of the canvas is (300, 300). Every coordinate you paint at must be between 0 and 600: a negative coordinate is off the canvas and paints nothing at all. Colours are hex strings like "#e08a72".

Follow the user brief for species and palette.

Paint one flower, centred, filling most of the frame, with a stem and leaves. Do not fill the canvas edge to edge.

Three numbers matter more than any adjective:
- Five petals. Paint each petal two or three times over, not once: a first pass at full size, then a smaller and more opaque pass inside it, and a small dark one near the centre. That layering is where a watercolour gets its depth, and it puts the whole painting at fifteen to thirty filled shapes. Keep the petals as five broad lobes, not fifteen separate little marks.
- Petals reaching 200 to 240 units from the centre, so the flower occupies the frame.
- Opacity never below 150, and 180 to 230 on the petals, with brush.fillBleed between 0.2 and 0.3. A dilute wash with a wide bleed disperses until no pigment reaches density and the flower comes out invisible.

These ten brush methods exist. Nothing else on `brush` exists, and there is no way to
name or select a brush: everything is painted as a filled shape. Do not call any other brush
method, and never use the bare p5 drawing functions such as ellipse, rect, vertex or beginShape:
  brush.scaleBrushes(factor)
  brush.noStroke()
  brush.fill(colorHex, opacity)
  brush.noFill()
  brush.fillBleed(amount)
  brush.fillTexture(amount, borderIntensity)
  brush.beginShape(curvature)
  brush.vertex(x, y)
  brush.endShape(true)
  brush.circle(x, y, radius, scribble)

colorHex is a string like "#e08a72". opacity runs 0 to 255. amount, curvature,
borderIntensity and scribble run 0 to 1.

Every mark is a filled shape. Build petals and leaves with brush.beginShape, a run of at least
three brush.vertex calls, then brush.endShape(true), and call brush.fill before each one. A stem
is a long narrow filled shape, not a line. brush.circle fills a disc.
"""

USER_TEMPLATE = (
    "Paint a {palette} {species} in watercolour: one bloom, seen from the "
    "front, with a stem and leaves, on coloured paper."
)


def build_prompts(combos: list[tuple[str, str]], n: int) -> list[dict[str, str]]:
    rows = []
    for species, palette in itertools.islice(itertools.cycle(combos), n):
        rows.append(
            {"prompt": USER_TEMPLATE.format(species=species, palette=palette)}
        )
    return rows


class FlowerPromptDataset(DatasetConfig):
    def __init__(self, prompts: list[dict[str, str]]) -> None:
        self.prompts = prompts

    def input_key(self) -> str:
        return "messages"

    def label_key(self) -> str:
        return "label"

    def rows(self) -> list[dict[str, Any]]:
        return [
            {
                "messages": [
                    {"role": "system", "content": SYSTEM_PROMPT},
                    {"role": "user", "content": r["prompt"]},
                ],
                "label": r["prompt"],
            }
            for r in self.prompts
        ]


N_TRAIN = 224
N_EVAL = 8

combos = list(itertools.product(SPECIES, PALETTES))
random.Random(7).shuffle(combos)
train_dataset = FlowerPromptDataset(build_prompts(combos, N_TRAIN))
eval_dataset = FlowerPromptDataset(build_prompts(combos, N_EVAL))

Creating a reward function

The reward function renders each sketch in a Modal Sandbox and uses an LLM judge to do pairwise comparisons. We serve the judge as an Endpoint.

def deploy_judge() -> Endpoint:
    print("deploying judges...")
    judge = Endpoint.launch(
        Qwen3_6_27B(),
        recreate_if_existing=True,
        endpoint_name="paint-flowers",
    )
    helpers.launch_hpsv3()
    judge.wait_until_ready(timeout=30 * 60)
    return judge


def render_in_sandbox(code: str) -> tuple[bytes | None, dict]:
    try:
        with Sandbox(
            image=helpers.renderer_image(),
            workdir="/render",
            timeout=300,
            cpu=1.0,
            memory=2048,
            block_network=True,
            app_name="training-gym-flower-render",
        ) as sandbox:
            sandbox.write("/render/render.js", helpers.RENDER_JS)
            sandbox.write("/render/sketch.js", code)
            result = sandbox.run(
                "node", "/render/render.js", "/render/sketch.js", timeout=180
            )
        out, err = result.stdout, result.stderr
        if "PNGB64:" in out:
            png = base64.b64decode(out.split("PNGB64:", 1)[1].strip())
            return png, {"render": "ok"}
        kind = "fail" if "SKETCH_ERROR:" in err else "unavailable"
        return None, {"render": kind, "stderr": err[-400:]}
    except Exception as e:
        return None, {
            "render": "unavailable",
            "stderr": f"{type(e).__name__}: {e}"[-400:],
        }


class RolloutSample(Protocol):
    response: str
    metadata: dict[str, Any] | None
    remove_sample: bool


def make_flower_rm(
    judge: Endpoint,
) -> Callable[..., Awaitable[float | None]]:
    async def flower_rm(
        args: Namespace, sample: RolloutSample, **kwargs: object
    ) -> float | None:
        code = helpers.extract_sketch(sample.response, base_model.parse_response)
        if code is None:
            reward, meta, png = 0.0, {"gate": "no valid sketch"}, None
        else:
            png, render_meta = await asyncio.to_thread(render_in_sandbox, code)
            reward, meta, png = await asyncio.to_thread(
                helpers.score_png, png, code, judge, render_meta
            )
        metadata = {**(getattr(sample, "metadata", None) or {}), **meta}
        if png is not None:
            metadata["image"] = png
        sample.metadata = metadata
        if reward is None:
            sample.remove_sample = True
        return reward

    return flower_rm

Training

After that, it’s simple to start training!

ROLLOUT_BATCH_SIZE = 8
N_SAMPLES_PER_PROMPT = 8


def build_config(judge: Endpoint) -> TrainConfig:
    return TrainConfig(
        model=base_model,
        dataset=train_dataset,
        eval_dataset=eval_dataset,
        recipe=Qwen3_5_4B_Recipe(
            custom_rm_function=make_flower_rm(judge),
            custom_reward_post_process_function=helpers.skip_infra_rewards,
            num_rollout=100,
            rollout_batch_size=ROLLOUT_BATCH_SIZE,
            global_batch_size=ROLLOUT_BATCH_SIZE,
            n_samples_per_prompt=N_SAMPLES_PER_PROMPT,
            save_interval=50,
            apply_chat_template_kwargs='{"enable_thinking": false}',
            image_overlay=lambda image: helpers.overlay_flower_image(image).env(
                {
                    IMAGE_SAMPLE_LIMIT_ENV: str(
                        ROLLOUT_BATCH_SIZE * N_SAMPLES_PER_PROMPT
                    )
                }
            ),
        ),
    )


if __name__ == "__main__":
    judge = deploy_judge()
    config = build_config(judge)
    run = config.launch()
    print(f"run id: {run.training_run_id}")
